AIRTEC Motorsport Auxiliary Radiators for BMW G8x M2/M3/M4 (Pair)

Technical Data

As part of our expanding BMW platform product range, AIRTEC Motorsport is proud to launch our auxiliary radiator upgrade (pair) for the G87 M2, G80/G81 M3 & G82/G83 M4 models for fast road or track use.

AIRTEC Motorsport’s solution to improving the auxiliary radiator was to utilise the available space behind the front bumper and develop a direct replacement radiator that’s wider, taller and thicker. This means capacity is increased by a 49% over standard, whilst frontal area is also increased by 13% to help cool the extra capacity.

The original radiators also feature a large, restrictive plastic protection mesh, which could potentially restrict flow at high speed, so our radiators feature our own less restrictive mesh that maintains good airflow whilst still offering protection against road debris. The original also uses plastic end tanks which can become brittle and leak with heat cycles and age, where is our solution features aluminium tanks.

Despite the significant increases and improvements, the radiators fit neatly behind the bumper and requires no modifications to fit, using the OEM rubber mounts and the original coolant connectors, scoops and air ducts.

Finished in a high-quality powder-coated black finish, the radiators come as a pair and also include a detailed installation guide.

Dimensions:
OEM radiator:
Height: 280mm
Width: 190mm
Depth: 34mm
Volume: 1.8-litres
Frontal area: 532cm²

AIRTEC Motorsport radiator:
Height: 285mm
Width: 210mm
Depth: 50mm
Volume: 2.9-litres
Frontal area: 599cm²

Fitment:
Replaces BMW part number: 17118095285
M2 – G87
M3 – G80/G81
M4  G82/G83

Features:

• 49% increase in capacity to the original
• 13% increase in frontal surface area
• Improved mesh design for airflow
• Offers improved cooling ability
• Uses original mounts, connectors and ducts
• Direct fit with no cutting or trimming
• Finished in durable black powder coat
• Comprehensive fitting guide
• Come as a pair

AIRTEC part no: ATRADBMW9
